At Co-Trust Tech Ltd, we specialize in high-performance energy storage solutions tailored for modern power demands. Our 48V LiFePO4 Lithium Battery are engineered for long-lasting performance, efficiency, and safety across a wide range of applications.
Key Features:
- Standard 19-inch design for high compatibility
- High temperature performance, below 60℃ without air-conditioning cooling, energy saving, intelligent management
- Long life, 6000 times @0.5C, 80%DOD, 25℃
- Modular, lightweight, easy operation and maintenance
- Default software anti-theft function (Optional)
- More than 10 years life time of design
- Support multi-module parallel connection, easy operation
- Support large current charge and discharge: Maximum 1C continuous charge and discharge
- Front operation, wiring, easy installation, and maintenance
- Multiple communication interfaces: RS485, RS232
- High compatibility BMS
- Telecom power systems other power station systems
| No | Details | N-LFP48100 | N-LFP48180 | N-LFP48200 |
| 1 | Appearance | Metal case | Metal case | Metal case |
| 2 | Nominal Voltage | 48V | 48V | 48V |
| 3 | Ah Capacity | 100Ah | 180Ah | 200Ah |
| 4 | Pack Dimension | 442*450*133mm | 442*520*155mm | 442*520*230mm |
| 5 | Energy Density | 4800Wh | 8640Wh | 9600Wh |
| 6 | Weight | 49Kg | 80.5kg | 80.5kg |
| 7 | Efficiency | >99.5% | >99.5% | >99.5% |
| 8 | Self Discharge/month | <3% | <3% | <3% |
| 9 | Design life(year) | >20 | >20 | >20 |
| 10 | Parallel connection | <15 | <15 | <15 |
| 11 | BMS Control | Yes | Yes | Yes |
| 12 | Protocol | RS-485 | RS-485 | RS-485 |
| 13 | Datalogger record and store | in real time | in real time | in real time |
| 14 | Charge Voltage | 48-54V | 48-54V | 48-54V |
| 15 | Working Tem. Range | -20~60 0C | -20~60 0C | -20~60 0C |
| 16 | Working Humidity Range | 5-95% | 5-95% | 5-95% |
| 17 | Max Continuous Discharging Current | 100A | 180h | 200h |
| 18 | Max Continuous Charging Current | 100A | 150A | 150A |
| 19 | Discharge output Internal Resistance | <10mOhm | <10mOhm | <10mOhm |
| 20 | Running Power Consumption | <30mA | <30mA | <30mA |
| 21 | Static Power Consumption | 10-50uA | 100-50uA | 100-50uA |
| 22 | BATTERY CELL SPECIFICATION | |||
| 23 | Cell Capacity | 100Ah | 180A | 200A |
| 24 | Cell Charge Voltage | 3.6V | 3.6V | 3.6V |
| 25 | Cell Max Continuous Discharge Current | 300 or 3C | 300 or 3C | 300 or 3C |
| 26 | Cell Standard charge and discharge current | 50 or 0.5C | 50 or 0.5C | 50 or 0.5C |
| 27 | Cycles life | 6000 cycles | 6000 cycles | 6000 cycles |
| 28 | Case Materials | Matel | Matel | Matel |
| 29 | Case IP rating | IP56 | IP56 | IP56 |
| 30 | Cell Type- Chemistry | LifePO4 | LifePO4 | LifePO4 |
| 31 | Cell Type | Prismatic | Prismatic | Prismatic |
| 32 | Temperature Specification | |||
| 33 | Discharge Temp | -20 to 60 0C | -20 to 60 0C | -20 to 60 0C |
| 34 | Charge Temp | 0 to 55 0C | 0 to 55 0C | 0 to 55 0C |
| 35 | Storage Temp | -30 to 60 0C | -30 to 60 0C | -30 to 60 0C |
| 36 | BMS High Temp Cut off | 80C | 80C | 80C |
| 37 | BMS Reconnect Temp | 50C | 50C | 50C |
| 38 | IP | 40 | 40 | 40 |
